Drive Axle for Forklifts

Forklift Drive Axle - A forklift drive axle is a piece of machinery which is elastically connected to a vehicle frame utilizing a lift mast. The lift mast is attached to the drive axle and could be inclined round the axial centerline of the drive axle. This is done by at least one tilting cylinder. Frontward bearing parts together with back bearing components of a torque bearing system are responsible for fastening the drive axle to the vehicle frame. The drive axle could be pivoted round a swiveling axis oriented horizontally and transversely in the vicinity of the back bearing elements. The lift mast is likewise capable of being inclined relative to the drive axle. The tilting cylinder is connected to the vehicle framework and the lift mast in an articulated fashion. This enables the tilting cylinder to be oriented practically parallel to a plane extending from the swiveling axis to the axial centerline.

Forklift models such as H45, H35 and H40 that are produced in Aschaffenburg, Germany by Linde AG, have the lift mast tilt capably affixed\connected on the vehicle frame. The drive axle is elastically attached to the forklift frame using many bearing devices. The drive axle contains a tubular axle body together with extension arms attached to it and extend rearwards. This particular kind of drive axle is elastically connected to the vehicle frame by rear bearing elements on the extension arms along with forward bearing devices situated on the axle body. There are two back and two front bearing devices. Each one is separated in the transverse direction of the forklift from the other bearing machine in its respective pair.

The braking and drive torques of the drive axle on tis particular model of forklift are sustained utilizing the extension arms through the back bearing elements on the framework. The forces created by the lift mast and the load being carried are transmitted into the floor or roadway by the vehicle framework through the front bearing elements of the drive axle. It is important to ensure the components of the drive axle are constructed in a firm enough method to maintain stability of the lift truck truck. The bearing elements can reduce minor bumps or road surface irregularities all through travel to a limited extent and give a bit smoother operation.
